don't bother with the valves.
$35 to replace, keep the vindicators if you want.
He needs a higher pressure valve than that. It's a high pressure steel tank.



tbone1004

Technical Instructor
ScubaBoard Supporter
Scuba Instructor
Messages
19,751
Reaction score
12,937
Location
Greenville, South Carolina, United States
# of dives
I'm a Fish!
He needs a higher pressure valve than that. It's a high pressure steel tank.


Officially that is correct, and you see them sold as 5000 vs 5250psi discs. IIRC the law surrounding pressure relief says it must not open at greater than 90% of test pressure. For an al80 that is 4500, and on the HP steels that's 4725, a delta of 5%. I would say that's pretty insignificant and would have 0 qualms using those discs on HP steel bottles. Illegal to go the other way and use the HP steel discs on an AL80 or on a LP steel tank, but perfectly fine to use a lower rated disc.


GJC

Contributor
Messages
738
Reaction score
650
Location
Southern California, USA
# of dives
200 - 499
Officially that is correct, and you see them sold as 5000 vs 5250psi discs. IIRC the law surrounding pressure relief says it must not open at greater than 90% of test pressure. For an al80 that is 4500, and on the HP steels that's 4725, a delta of 5%. I would say that's pretty insignificant and would have 0 qualms using those discs on HP steel bottles. Illegal to go the other way and use the HP steel discs on an AL80 or on a LP steel tank, but perfectly fine to use a lower rated disc.
Agree and I would not personnally have an objection to using it myself, but I wouldn't recommend it to someone I don't know and that might have problems getting it filled past 3000 by a dive shop that notices the valve marking.

OP
Bearded Diver

Bearded Diver

Contributor
Messages
93
Reaction score
15
Location
Florida
# of dives
100 - 199
vinegar and a toothbrush will do wonders on the valve. Clean up the hydro mark and then paint with three layers of nail polish. You probably have everything you need at home.
Minus the nail polish lol. Thanks 😊


Divin'Papaw

ScubaBoard Supporter
ScubaBoard Supporter
Messages
7,165
Reaction score
4,939
Location
Florida
# of dives
500 - 999
These are almost $85 just want to clean them up. Now if these were really antique valves, I’d agreed with you, plus I unfortunately don’t dove enough where there is significant use to my tanks. Most diving actually happens on the west coast.

Seriously. Just replace them. $50 each for 3442 psi Thermo Valves from DGX with free shipping. $100 and you’re done. No guess work. Brand new valves that’ll last you years without issue. You can easily end up spending just about that much on having them rebuilt and the burst assemblies replaced.

OP
Bearded Diver

Bearded Diver

Contributor
Messages
93
Reaction score
15
Location
Florida
# of dives
100 - 199
vinegar and a toothbrush will do wonders on the valve. Clean up the hydro mark and then paint with three layers of nail polish. You probably have everything you need at home.
Thanks John

OP
Bearded Diver

Bearded Diver

Contributor
Messages
93
Reaction score
15
Location
Florida
# of dives
100 - 199
Seriously. Just replace them. $50 each for 3442 psi Thermo Valves from DGX with free shipping. $100 and you’re done. No guess work. Brand new valves that’ll last you years without issue. You can easily end up spending just about that much on having them rebuilt and the burst assemblies replaced.
Fair point. Might just replace them,


Thunder Struck

Contributor
Messages
142
Reaction score
185
Location
Clark Co. NV
# of dives
100 - 199
The corrosion on the valve looks pitted. So even if you cleaned it up, it'll still be pitted. And unless you somehow coated it, it's just going to corrode again. Either put on a new valve or just run with it. The surface corrosion won't hurt as long as the surface is smooth where the o-ring seats.

As for the hydro stamp, the vinegar water solution with a wire brush should work. After cleaning and drying you can mask it off, hit it with some primer then some paint to match.

OP
Bearded Diver

Bearded Diver

Contributor
Messages
93
Reaction score
15
Location
Florida
# of dives
100 - 199
The corrosion on the valve looks pitted. So even if you cleaned it up, it'll still be pitted. And unless you somehow coated it, it's just going to corrode again. Either put on a new valve or just run with it. The surface corrosion won't hurt as long as the surface is smooth where the o-ring seats.

As for the hydro stamp, the vinegar water solution with a wire brush should work. After cleaning and drying you can mask it off, hit it with some primer then some paint to match.
Thanks. Figured it wouldn’t be “new” again but as long as the area where my reg goes is clean, I’m good with it. Thanks for your input 😊
