When I started diving a few years ago I purchased a number of lithium-ion dive lights from Dive Gear Express. They were a mixture of the DGX600 and DGX800 lights. Nearly identical lights are sold under various other brands. They're bright with Dive Gear Express claiming 600 and 800 out-the-front lumens as the model number implies. I have found that they have practical run-times of approximately 50 minutes and approximately 90 minutes, respectively. They use 18650 cells that are removed and recharged in a separate device. My kids use them too. I liked them quite a bit but with time I discovered several significant drawbacks:
  1. Over five years we have had three of the lights fail, one during its warranty period.
  2. We had one light flood because the diver using it twisted it the wrong way when trying to turn it on.
  3. The m/v Conception fire, the loss of a private yacht due to a Lithium-ion battery fire in a power tool, and the ongoing problems airlines have had with lithium-ion battery fires have led me to look for alternatives. My concerns are particularly acute for 18650 lithium-ion cells that are not incorporated into a pack and that therefore lack any sort of cushioning or protection against impact e.g. dropping on the floor, crushing forces, short circuits. To be sure this can be mitigated through careful handling and use of a protective holder, but it requires awareness.
  4. Lithium-ion cells have relatively high self-discharge rates such that lights using them have to be recharged periodically even if they have not been used.
  5. Safety aside, air travel with the 18650 cells requires attention to compliance, and a charger or several spares must be carried since there is no practical means of purchasing fully-charged 18650s at a dive destination.
I still use lithium-ion batteries for other applications, among them the prismatic lithium-polymer batteries in my laptop and phone, and the larger packs of 18650 and 21700 cells in power-tool batteries. These uses are not without risk but I believe that there is no feasible alternative due to the size and weight constraints and power requirements for these applications. I believe the risk is lower because the electronic device or the pack provide physical protection.

After experimenting with several lights, I have settled upon the Princeton Tec Torrent. I use low self-discharge NiMH rechargeable batteries in it -- it takes 8 AAs. Light output is specified as 500 lumens and in practice seems somewhat less than the DGX600 but still more than adequate. I find that I get just over two hours at nearly full brightness and several hours of usable light beyond that, both improvements over the DGX800 and significantly longer than the DGX600. The switch is well thought out and separate from the means of disassembly. The light is somewhat larger and heavier than the DGX600 but shorter than the DGX800. The NiMH batteries have an excellent safety record and can be placed in checked baggage. They hold their charge for years if unused, and it is possible to substitute locally purchased one-use AA batteries should that become necessary.

I also experimented with the Princeton Tec Impact XL but do not believe it meets my needs. It has the twist-style switch that has been problematic for me in the past (when other divers use my light) and has less light output in exchange for somewhat less weight, bulk, and cost.

Past discussions at SB have framed non-lithium-ion lights as non-starters due to insufficient light output and a lack of high-quality diving-oriented choices. While that may have been true in the past, these lights are competitive with lithium-ion lights and offer an alternative for divers who seek one.

OP
2airishuman

2airishuman

Contributor
Messages
2,650
Reaction score
1,945
Location
Greater Minnesota
# of dives
100 - 199
Some photos of the DGX600, Princeton Impact XL, and Princeton Torrent. Weights include batteries.


Attachments

  • PXL_20211031_180440782.jpg
    156.9 KB · Views: 45
  • PXL_20211031_180506130.jpg
    108.2 KB · Views: 42
  • PXL_20211031_180514958.jpg
    111.7 KB · Views: 41
  • PXL_20211031_180529619.jpg
    101.1 KB · Views: 45

Jim Lapenta

Contributor
Scuba Instructor
Divemaster
Messages
17,583
Reaction score
10,193
Location
Canonsburg, Pa
# of dives
1000 - 2499
Princeton lights aren't bad lights. Until the switches fall off and the light floods. I've had 5 or 6 different ones do this. Make sure you check the screws on the switches periodically.


tbone1004

Technical Instructor
ScubaBoard Supporter
Scuba Instructor
Messages
19,848
Reaction score
13,135
Location
Greenville, South Carolina, United States
# of dives
I'm a Fish!
Your comment about self discharge is incorrect. Liion has almost negligible self discharge. The BMS on the cell may be the culprit or the light itself if it is a push button, but the cell itself has negligible self discharge.

There are no good options for full size lights because of the capacity issues and there are extremely limited options in the backup light world as you have found. I have several that use aaa or aa batteries with my favorite being the dive rite bx1 that has 3xaaa eneloops in it but it’s not what I’d use for a primary.


Gone for diving

Contributor
Messages
991
Reaction score
658
Location
Ont
Lifepo4 are quite safe, and stable, I don't think they make them in 18650 size,
I know they come in 32650, but there are not to many flashlights that use the size,

We had one light flood because the diver using it twisted it the wrong way when trying to turn it on.
Dosen't have anything to do with lithium batteries,

I have a few non lithium flashlights that use this system,
In fact it the most simple and reliable underwater SW in my opinion,


loosenit2

si respiratio sub aqua amet
Messages
1,015
Reaction score
1,257
Location
Virginia
# of dives
I'm a Fish!

i've tested DGX 600 with CR123a batteries too...works and gets a burn-time of over 2:30.


Darnold9999

Contributor
Messages
2,718
Reaction score
990
Location
Victoria BC Canada
# of dives
500 - 999
Have had one of these (Princeton tec LED lights) for about ten years and it has been bulletproof and subject to a fair amount of abuse - the lens is well scratched It now lives on my boat as a waterproof emergency light. Went to a smaller, but brighter light from NiteScuba. It runs on a 18650 cell however, and only time will tell if the switch will survive as long.


Whitrzac

Contributor
Messages
337
Reaction score
245
Location
WI
Lifepo4 are quite safe, and stable, I don't think they make them in 18650 size,
I know they come in 32650, but there are not to many flashlights that use the size,


Dosen't have anything to do with lithium batteries,

I have a few non lithium flashlights that use this system,
In fact it the most simple and reliable underwater SW in my opinion,


I use to buy the black&decker VPX packs to harvestthe A123 lifepo4 cells out of, lol.



divinh

Contributor
Messages
1,208
Reaction score
722
Location
San Francisco
# of dives
100 - 199
I originally bought a DGX switch light, but the switch failed on first use underwater. DGX replaced with a twist light, at my request. I don't understand why there aren't twist direction indicators to prevent accidental floods.


tbone1004

Technical Instructor
ScubaBoard Supporter
Scuba Instructor
Messages
19,848
Reaction score
13,135
Location
Greenville, South Carolina, United States
# of dives
I'm a Fish!
I use to buy the black&decker VPX packs to harvestthe A123 lifepo4 cells out of, lol.

Safer sure but have to weigh the fact that they’re only half the capacity of liion which means carrying twice as many lights but also double the charging!
I use lifepo4 for lots of things where energy density isn’t critical but in the high powered flashlights we use today, it certainly is
